If you require a visualization of the measurements provided by the sensor, WayCon offers you the optimal solution for every sensor signal with the series PAX, REX and the Magnescale displays. The modular design of our displays enables an upgrade with a variety of output cards that enable further processing of the data by controller or PC. Functions, such as the zeroing, set limits, linearization and much more make the devices truly multi-function displays.
|
Display axes |
1, 2, 3 |
|
Application |
Standard counter |
|
Input digital |
SJ300, SJ700, GBER, PL20C, DK-Messtaster |
|
Sensor supply |
yes |
|
Digiits |
7 |
|
Resolution, selectable |
0.1, 0.5, 1, 2, 5, 10, 20, 25, 50, 100 µm |
|
Download |
|
|
Display axes |
1, 2, 3 |
|
Application |
Counter for milling machines and lathes |
|
Input digital |
SJ300, SJ700, GBER, PL20C, DK digital gauge |
|
Sensor supply |
yes |
|
Digits |
7 |
|
Resolution, selectable |
0.1, 0.5, 1, 5, 10 µm, 1 s, 10 s, 1 min, 10 min |
|
Download |
|
|
Display axes |
1 and 2 |
|
Input digital |
DT/ DK/ DK800S |
|
Sensor supply |
yes |
|
Digits |
7 |
|
Outputs |
- |
|
Interfaces |
versions with RS232 or BCD |
|
Download |
|
|
Display axes |
2 |
|
Input analogue |
0...10 V, 4...20 mA, 2 x 0...10 V, 4...20 mA |
|
Sensor supply |
yes, up to 50 mA |
|
Digits |
5 |
|
Outputs |
various by optional plug-in cards |
|
Interfaces |
various by optional plug-in cards |
|
Download |
|
|
Display axes |
1 |
|
Input digital |
TTL, THL |
|
Sensor supply |
yes, up to 50 mA |
|
Digits |
6 |
|
Outputs |
various by optional plug-in cards |
|
Interfaces |
various by optional plug-in cards |
|
Download |
|
|
Display axes |
1 / 2 |
|
Input analogue |
0...10 V, 4...20 mA, 2 x 0...10 V, 4...20 mA |
|
Sensor supply |
yes, up to 50 mA |
|
Digits |
5 |
|
Outputs |
various by optional plug-in cards |
|
Interfaces |
various by optional plug-in cards |
|
Download |
|
|
Display axes |
1, 2 |
|
Input digital |
TTL, HTL |
|
Frequency |
up to 1 MHz |
|
Sensor supply |
yes, up to 50 mA |
|
Digits |
6 to 8 |
|
Outputs |
version with 2 presets and switching output |
|
Interfaces |
version with RS232 and RS485 and analogue |
|
Download |
|
